Description
Features
- Engine Options: Briggs, Kawasaki & Kohler
- Available Deck Sizes: 48″, 54″ & 60″
- Patented Independent Front Suspension
- 3/16″ Or 7-Gauge All Steel, Formed And Welded Deck With Reinforced Edges
- Dual Hydro-Gear 3100 Series Integrated Drive Systems
Additional Features
- Heavy-Gauge, All-Steel, All-Welded Frame
- Industry-Leading 3/8″ Steel Front Forks
- Peer, Maintenance-Free Spindles
- Deck Lift Pedal With Deck Dial Adjustment
- Seat Lifts For Easy Maintenance And Cleaning
- Adjustable Steering Arms
- Electric Pto
- Comfort Seat
Specifications
- Engine Manufacturer: Kawasaki
- Displacement: 726cc
- Engine Power: 24hp
- Cooling: Air-Cooled
- Engine: Model: Fr730v
- Fuel Type: Unleaded Gasoline
- Transmission: 3100 Hydro-Gear® 10cc Integrated Transaxle
- Tires, Rear Specification: 22×11-10 Reaper®
- Tires, Front Specification: 13×6-6 Smooth
- Operating Speed: Ground Speed (Forward): Up To 7 Mph
- Deck Thickness: 3/16″ Or 7-Gauge Thick Solid Steel
- Cutting Width: 54″
- Height: 46″ | Cutting: 1.5″ – 4.5″ With Deck Height Control System
- Length: 74.5″
- Width: Chute Up / Chute Down: 58″/67″
- Fuel Capacity: 6.5 Gallons
- Weight: 839 Lbs.
- Features: Lift & Height Adjustment: Foot-Assist Manual Lift With Dial-Style Height Adjustment.
